Yucoo 48V 10A rack mount switching power supply 480W ac to dc rectifier converter power rectifier
USD225-235
Customized logo (Min. Order: 300 Sets)
Customized packaging (Min. Order: 300 Sets)
Graphic customization (Min. Order: 300 Sets)
Trade Assurance
On-time Dispatch Guarantee
Refund Policy
Quick Details
- Product name:
- rack mount switching power supply
- Model Number:
- YK-AD4810
- Input Voltage:
- 1phase AC220V±15% 50/60Hz, 220V
- Output Voltage:
- 48VDC
- Output Current:
- 0-10A optional
- AC wide input :
- 1phase AC220V±15% 50/60Hz
- Output Frequency:
- 50/60HZ
- Warranty:
- 1 YEAR
- Dimensions:
- 235*485*45
- Weight:
- 4
Product Description
1.Wide range of input voltage
2.Continuously adjustable DC output voltage
3.High precision of voltage regulation
4.Low output noise ripple
5.Intelligent fan
6.Strong protection function
7.Limiting protection of output power‘
8.Over current and short circuit protection
9.Input overvoltage and low-voltage protection
10.Input overvoltage and low-voltage protection
11.Over temperature protection
12.High efficient, small volume and light weight
13.We can provide 19-inch rack mount and stand-alone
Product Parameters
| Model Number | YK-AD4810 |
Output Power | 480W |
Output Type | 1phase |
Output Frequency | 50/60HZ |
Output Current | 10A |
Warranty | 1 Year |
Power Factor | ≥0.99 |
Efficiency | ≥82% |
Insulating Strength | Input—Shell (ground)1500VAC Input—Output 1500VAC Input—Output 500VAC |
Dynamic Response | 20% ~ 100% step load≤200 170V ~ 265Vac step electric fence ≤200 |
Output Overvoltage Protection | 60±1vdc |
Output Limiting Current Protection | 6±0.5adc |
Input Low-voltage Limiting Current Protection | ≤160±10vac |
Input High-voltage Limiting Current Protection | ≤280±10vac |
Overtemperature Protection | 85±5°C |
MTBF | 100000 |
Dimensions | 235*485*45mm/244*485*45mm(with battery interface) |
N.W. | 4KG |
