Yucoo 120vac off-grid 3kva 24v telecom pure sine wave inverter 2400w

USD 720

Intput Voltage

24Vdc

Output Voltage

120Vac

Output Power

2400W

Customization

Customized logo (Min. Order: 300 Sets)

Customized packaging (Min. Order: 300 Sets)

Graphic customization (Min. Order: 300 Sets)

Protection

Trade Assurance

On-time Dispatch Guarantee

Refund Policy

Product Details

Quick Details

Features

1. Software protection and hardware protection, high reliability.

2. Perfect protection: input polarity reverse, input over/under voltage, over current,

short circuit, over heat.

3. 3 Layers composite filter and magnetism shielded which and reduce the reflect noise

voltage to the input port, perfect electromagnetism compatibility.

4. Intelligent Fan cooling.

5. Able to connect with pure sensibility load (Should reduce voltage).

Product Parameters

Model (YKDA-HT)**		1000	2000	3000	4000			5000
Rate capacity（VA）		1	2	3	4			5
Rate output power		800	1600	2400	3200			4000
Dc input	Rated input voltage	24VDC
	Rate input Current	42A	83A	125A	167A			20A
	Shut down voltage range	20V--30V
	Start-up voltage range	22V—28V
	Reflect noise current	≤10%
AC Input	Allow bypass voltage	132V-90V(±10V)
	Rate input Current	8.3A	16.6A	25A		33.3A		42A
	Bypass switch time	≤5ms
AC output	Rate output voltage and frequency	120Vac,50Hz
	Waveform	Pure Sine Wave
	Rate output current	6.7A	13.3A	20A	27A		33.3A
	Output voltage precision	120Vac，50HZ/60HZ
	Output frequency precision	50±0.1%Or60±0.1%
	Waveform distortion	≤3% (linear load) (THD)
	Dynamic respond time	5% (Load0←→100%)
	Power factor	0.7/0.8
	Overload ability	120%,30s
	Efficiency	≥85%
Insulating intensity		1500Vac,1min
Noise (1m)		≤40dB
Operation temperature		50±0.1%Or60±0.1% -20℃~+50℃
Humility		0～90%, non condensing
Operation altitude		≤1000m
Inverter status		Mains supply is normal, invert normal, battery under voltage, output overloading
Protect function		Input under/over voltage, output overloading, short circuit, city power high-low voltage protection
Output mode		Terminal block
